Transfer Carriage
The MSB Transfer Carriage is a fully hydraulic, pit-mounted solution designed for seamless and efficient transfer of FFB cages between steriliser railtracks and cage tipper railtracks. Engineered for reliability and precision, it ensures smooth cage movement while optimizing mill operations.
More Info
Product Description
Built on a robust mainframe resting on four drive wheels, the MSB Transfer Carriage is capable of handling 5–16 tonne FFB cages per transfer. The unit operates through hydraulic motors powered by a central powerpack, ensuring efficient movement along the railtrack. With its drag chain conveyor system, cages are effortlessly transferred in and out of the carriage, making it a durable and low-maintenance solution for palm oil mills.
Advantages
- High Capacity – Capable of transferring up to 20 cages per hour.
- Smooth & Controlled Movement – Equipped with multiple travel speeds (fast, medium, and creep) for safe and efficient operations.
- Hydraulic Efficiency – Operated by a hydraulic motor system with built-in relief valve, pressure gauges, and check valves for reliability.
- Durable Construction – Heavy-duty frame and precision-built drive wheels designed for long service life.
- Customizable Options – Fabrication available for cage capacities ranging from 5 to 16 tonnes.
| Specification | |
|---|---|
| Capacity | 20 cages/hr |
| Cage Handling | 5 – 16 tonnes per transfer |
| Long Travel Speed | Fast: 20 m/minMedium: 12.5 m/minCreep: 0.5 m/min |
| Cage In/Out Speed | 15 m/min |
| Hydraulic System | Hydraulic pump, oil tank, hydraulic motor, tubing, lever control, relief valve, pressure gauges, pump strainer, check valve, etc. |
| Electric Motor | 5.5 kW / 4 pole TEFC Squirrel Cage Induction Motor |
| Type | Pit-mounted, fully hydraulic |
